EcoFlow Sustainable: The Green Engineering Solution in Stainless Steel Locking Ball Valves

MOQ:	100kgs
Price:	Negotiation
Standard Packaging:	Standard sea worth bundles,Standard Plywood cases
Delivery Period:	3-10days
Payment Method:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

YUHAO

Certification

ASTM, AISI, GB, DIN, JIS

Model Number

Stainless steel ball valves

Standard:

ASTM, JIS, GB, AISI, DIN, BS,EN

Bonnet Style:

Threaded Or Welded

Applications:

Industrial, Chemical, Oil & Gas, Water Treatment, Etc.

Thread:

NPT, BSPT...

Port Size:

1"-48"

Pressure:

High/Medium/Low Pressure

Working Pressure:

PN，PSI

Color:

Silver,chrome,white,Customer's Request,Grey

Temperature Of Media:

Medium Temperature,Normal Temperature,High Temperature

Highlight:

stainless steel locking ball valve

ecoflow sustainable ball valve

green engineering stainless steel valve

Product Description

EcoFlow Sustainable: The Green Engineering Solution in Stainless Steel Locking Ball Valves

►Products description

Meeting the growing need for sustainable industrial solutions, EcoFlow Sustainable combines ecological responsibility with uncompromising performance. Our valves are designed for minimal environmental impact throughout their lifecycle.

Green Engineering Breakthroughs

CircularSource™ Materials: 80%+ recycled stainless steel content
Eco-Seal Technology: Zero fugitive emissions certification
Energy Smart Design: 30% lower operating torque reduces energy consumption
Lifecycle Optimization: 50-year design life with full recyclability
Carbon Neutral Manufacturing: Plant-powered production facilities

Sustainable Applications

Renewable energy plants
Green hydrogen systems
Waste-to-energy facilities
LEED-certified buildings
Environmental remediation projects

Environmental Certifications

Environmental Product Declaration (EPD)
LEED contribution documentation
Carbon footprint verified by third parties
Meets ISO 14000 environmental standards

►Product size

PN1.6MPa Main connection dimensions and weight

DN	15	20	25	32	40	50	65	80	100	125	150	200
L	130	140	150	165	180	200	220	250	280	320	360	400
H	59	63	75	85	95	107	142	152	178	252	272	342
W	130	130	160	180	230	230	400	400	650	1050	1050	1410
Wt(Kg)	2.5	3	5	6	7	10	15	19	33	58	93	160

PN2.5MPa Main connection dimensions and weight

DN	15	20	25	32	40	50	65	80	100	125	150	200
L	130	140	150	165	180	200	220	250	320	400	400	550
H	59	63	75	97	107	142	152	178	252	272	342	345
W	130	130	160	230	230	400	400	700	1100	1100	1500	1500
Wt(Kg)	2.5	3	5	6	7.5	10	15	20	33	60	93	175

PN4.0MPa Main connection dimensions and weight

DN	15	20	25	32	40	50	65	80	100	125	150	200
L	130	140	150	180	200	220	250	280	320	400	400	400
H	59	63	75	85	95	107	142	152	178	252	272	342
W	130	130	160	230	230	400	400	700	1100	1100	1500	1500
Wt(Kg)	3	4	5	7	9	12	18	28	46	75	106	190

PN6.4MPa Main connection dimensions and weight

DN	15	20	25	32	40	50	65	80	100	125	150	200
L	165	190	216	229	241	292	330	356	432	508	559	660
H	59	63	75	97	107	142	152	178	252	272	305	398
W	130	130	160	230	230	400	400	700	1100	1100	1500	1800
WtKg)	6.5	7	8	12	14	18	28	40	65	98	140	250

PN10MPa Main connection dimensions and weight

DN	15	20	25	32	40	50	65	80	100	125	150	200
L	165	190	216	229	241	292	330	356	432	508	559	660
H	59	63	75	97	107	142	152	178	252	272	305	398
W	130	130	160	230	230	400	400	700	1100	1100	1500	1800
Wt(Kg)	6.5	7	10	15	18	25	32	46	75	-	-	-

►Factory Shoot

EcoFlow Sustainable: The Green Engineering Solution in Stainless Steel Locking Ball Valves 0

EcoFlow Sustainable: The Green Engineering Solution in Stainless Steel Locking Ball Valves 1

EcoFlow Sustainable: The Green Engineering Solution in Stainless Steel Locking Ball Valves 2
