Flange Pressure Class Range at YUHAO: Full-Spectrum Coverage Across Every Major Rating System
Pressure rating is the single most critical parameter in flange selection. It determines wall thickness, bolt size and quantity, gasket seating requirements, and ultimately the safe operating envelope of the entire piping system. YUHAO Hardware delivers complete pressure class coverage spanning Class 150 through Class 2500 (ANSI/ASME), PN 2.5 through PN 400 (EN 1092-1), 5K through 63K (JIS), and PN 6 through PN 100 (GOST) — ensuring that every pressure requirement, from low-pressure utility water to ultra-high-pressure hydrogen service, is met by a fully certified YUHAO flange.
Understanding Pressure Rating Systems: They Are Not Interchangeable
A common procurement mistake is assuming that flanges from different standard systems are interchangeable at similar pressure levels. This is incorrect. ANSI Class, EN PN, JIS K, and GOST PN are fundamentally different rating methodologies with distinct dimensional tables, material de-rating curves, and temperature-pressure relationships. Each system must be applied strictly within its own code framework.
ANSI/ASME Class System: The Global Benchmark
Class
Max Working Pressure (psig @ 100°F, A105 CS)
Typical Applications
Class 150
285 psig (19.6 bar)
Low-pressure water, drainage, vent lines, HVAC
Class 300
740 psig (51.0 bar)
General process piping, steam, compressed air
Class 400
985 psig (67.9 bar)
Mid-pressure hydrocarbon, boiler feedwater
Class 600
1,480 psig (102 bar)
High-pressure refinery, chemical injection, gas transmission
Class 900
2,220 psig (153 bar)
High-pressure gas, offshore topside, wellhead connections
Class 1500
3,705 psig (255 bar)
Subsea pipelines, superheated steam, hydrogen service
Class 2500
6,170 psig (425 bar)
Ultra-high-pressure — ammonia synthesis, HPHT wellheads
EN 1092-1 PN System: Europe's Precision Rating
The PN (Pressure Nominale) system uses a bar-based designation at reference temperature, with a different material de-rating methodology than ASME. EN 1092-1 covers 12 pressure levels from PN 2.5 to PN 400, the widest grading resolution of any single standard.
PN Rating
Approx. ASME Equivalent
Typical Applications
PN 6 / PN 10 / PN 16
Class 150
Water distribution, building services, irrigation
PN 25 / PN 40
Class 300
Industrial process, steam, compressed air, HVAC
PN 63 / PN 100
Class 400–600
Chemical process, refinery, gas transmission
PN 160 / PN 250
Class 900–1500
High-pressure gas, offshore, power generation
PN 320 / PN 400
Class 2500
Ultra-high-pressure — petrochemical, HP/HT wells
JIS K-Rating & GOST PN: Regional Specialists
JIS B2220 (Japan): The K-rating system (5K, 10K, 16K, 20K, 30K, 40K, 63K) is derived from kgf/cm². A JIS 10K flange approximates Class 150 performance, while JIS 63K approaches Class 600. However, JIS flanges are dimensionally unique — bolt circles, flange thicknesses, and facing dimensions differ from both ASME and EN counterparts. They must never be substituted across standards.
GOST 12820 (Russia & CIS): Covers PN 6 through PN 100 with additional requirements for low-temperature ductility. GOST flanges in 09G2S steel are rated for service down to -70°C — a capability beyond standard ASME and EN material specifications. This makes them essential for Arctic and Siberian pipeline projects.
Pressure Class vs. Temperature: The De-Rating Curve
A critical concept often overlooked: a flange's pressure rating is temperature-dependent. A Class 300 carbon steel flange rated for 740 psig at 100°F drops to approximately 505 psig at 750°F. Stainless steel grades follow a different de-rating profile. YUHAO provides full pressure-temperature rating tables per ASME B16.5 Annex for every material grade, enabling accurate engineering-level selection.
YUHAO: One Partner, Every Pressure Class
YUHAO is one of the few manufacturers globally with the forging, machining, and testing capability to produce flanges across the complete pressure spectrum of all four major rating systems — from Class 150 utility flanges to Class 2500 ultra-high-pressure weld-neck flanges, from PN 2.5 water-service flanges to PN 400 HP/HT flanges. This full-spectrum capability ensures that project owners can consolidate their entire pressure-class matrix under one supplier, with uniform quality control and full material traceability per EN 10204 3.1.
For inquiries regarding specific pressure ratings, material grades, or project pipe-class specifications, contact YUHAO with your requirements. Our engineering team provides pressure-class-matched quotations within 24 hours.
View More
YUHAO Flange Facing Types & Sealing Surfaces: RF, FF, RTJ, T/G, M/F — Every Sealing Solution Covered
2026-08-12
.gtr-container-flange789 {
font-family: Verdana, Helvetica, "Times New Roman", Arial, sans-serif;
color: #333;
line-height: 1.6;
padding: 15px;
box-sizing: border-box;
max-width: 100%;
overflow-x: hidden;
}
.gtr-container-flange789 p {
margin-bottom: 1em;
text-align: left !important;
font-size: 14px;
}
.gtr-container-flange789 strong {
font-weight: bold;
color: #001D56;
}
.gtr-container-flange789 .gtr-heading-main {
font-size: 18px;
font-weight: bold;
color: #001D56;
margin-bottom: 1.2em;
text-align: left !important;
}
.gtr-container-flange789 .gtr-heading-sub {
font-size: 16px;
font-weight: bold;
color: #001D56;
margin-top: 1.5em;
margin-bottom: 1em;
text-align: left !important;
}
.gtr-container-flange789 .gtr-table-wrapper {
width: 100%;
overflow-x: auto;
margin-bottom: 1.5em;
}
.gtr-container-flange789 table {
width: 100%;
border-collapse: collapse !important;
border-spacing: 0 !important;
margin-bottom: 1em;
min-width: 600px;
}
.gtr-container-flange789 th,
.gtr-container-flange789 td {
padding: 10px 12px !important;
border: 1px solid #ccc !important;
text-align: left !important;
vertical-align: top !important;
font-size: 14px !important;
word-break: normal !important;
overflow-wrap: normal !important;
}
.gtr-container-flange789 th {
background-color: #e0e6f0;
color: #001D56;
font-weight: bold !important;
border-color: #001D56 !important;
}
.gtr-container-flange789 tr:nth-child(even) {
background-color: #f9f9f9;
}
@media (min-width: 768px) {
.gtr-container-flange789 {
padding: 25px 40px;
}
.gtr-container-flange789 .gtr-heading-main {
font-size: 24px;
}
.gtr-container-flange789 .gtr-heading-sub {
font-size: 20px;
}
.gtr-container-flange789 .gtr-table-wrapper {
overflow-x: visible;
}
.gtr-container-flange789 table {
min-width: auto;
}
}
Flange Facing Types & Sealing Surfaces at YUHAO: Engineered for Every Service Condition
The flange facing is where sealing happens — and choosing the wrong facing type is one of the most common causes of flange leakage in industrial piping systems. The facing geometry determines gasket compatibility, bolt load distribution, and long-term seal integrity under temperature and pressure cycling. YUHAO Hardware manufactures flanges with all five primary facing configurations: Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ), Tongue & Groove (T&G), and Male & Female (M&F), ensuring compatibility with any project gasket specification and service condition.
Why Facing Type Selection Is Critical
Each facing type creates a fundamentally different sealing mechanism. RF relies on gasket compression within a raised serrated surface. RTJ uses metal-to-metal contact with an oval or octagonal ring compressed into a precision-machined groove. T&G and M&F provide positive mechanical interlock for self-aligning, confined-gasket sealing. Selecting the wrong facing can result in gasket blowout, uneven bolt stress, or incomplete seating — all leading to fugitive emissions and potential safety incidents.
Flat Face (FF)
Design: The entire flange face is flat and machined smooth, with no raised portion. The gasket covers the full face area from bolt circle to bore.
Applications: FF flanges are almost exclusively used with cast iron flanges and equipment — such as pump casings, valve bodies, and cast iron pipe — where the brittle material cannot tolerate the bending stress induced by a raised face. They are also common in low-pressure utility services (water, drainage, HVAC) and where full-face soft gaskets (rubber, fiber, PTFE) are specified.
Limitations: Not recommended for high-pressure or high-temperature service. Typically limited to Class 150/300 and PN 16/40 applications.
Raised Face (RF)
Design: A raised, serrated (phonographic finish) surface protrudes 1.6 mm (1/16″) for Class 150/300 and 6.4 mm (1/4″) for Class 400 and above. The gasket sits on the raised portion only, concentrating bolt load over a smaller area for higher seating stress.
Applications: RF is the most widely used facing type globally, suitable for the broadest range of services: process hydrocarbons, steam, chemicals, water, compressed air, and heat transfer fluids. The serrated finish (125–250 AARH / 3.2–6.3 μm Ra) provides grip for soft and semi-metallic gaskets including spiral wound, kammprofile, and compressed fiber types.
Advantages: Universal compatibility, simple gasket installation, forgiving of minor misalignment. Covers Class 150 through Class 2500.
Ring Type Joint (RTJ)
Design: A precision-machined V-shaped groove is cut into the flange face to accept a solid metal ring gasket (octagonal or oval cross-section, typically in soft iron, stainless steel, or alloy). The ring deforms plastically into the groove under bolt preload, creating a metal-to-metal pressure-energized seal.
Applications: RTJ is the default specification for high-pressure, high-temperature (HP/HT) services — Class 600 and above, typically Class 900/1500/2500. Common in wellhead equipment, subsea pipelines, hydrogen service, superheated steam, and refinery hydrocrackers. RTJ is also mandatory for many NACE MR-0175 sour service applications.
Advantages: The most reliable seal under extreme pressure and temperature cycling. Self-energizing — higher pressure improves the seal. Fire-safe by design.
Tongue & Groove (T&G) and Male & Female (M&F)
Design: Both are paired facing systems — one flange has a raised feature (tongue or male), the mating flange has a matching recess (groove or female). The gasket is fully confined within the recess, eliminating the risk of blowout and ensuring perfect alignment during assembly.
Feature
Male & Female (M&F)
Tongue & Groove (T&G)
Gasket Confinement
Partially confined — gasket sits in female recess
Fully confined — gasket entirely enclosed in groove
Alignment
Self-aligning, good for large flanges
Precision alignment, tightest control
Typical Use
Heat exchanger shells, vessel covers
Toxic/lethal service, high vacuum, compressor casings
Gasket Types
Soft, spiral wound, metal-jacketed
Soft, PTFE envelope, thin metal
Applications: T&G and M&F are specified where gasket blowout is absolutely unacceptable — toxic chemical service, lethal gas lines, high-vacuum systems, and compressor or turbine casing flanges. The confined gasket design provides the highest safety margin against fugitive emissions.
YUHAO Facing Type — Quick Reference
Facing Type
Pressure Rating
Gasket Type
Key Service
Flat Face (FF)
Class 150–300 / PN 16–40
Full-face soft gasket
Cast iron equipment, low-pressure utility
Raised Face (RF)
Class 150–2500 / PN 10–400
Spiral wound, kammprofile, fiber
General process — widest application
Ring Type Joint (RTJ)
Class 600–2500 / PN 100–400
Solid metal ring (octagonal/oval)
HP/HT, sour gas, subsea, hydrogen
Tongue & Groove (T&G)
Class 150–2500 (all)
Confined soft/PTFE/metal
Toxic service, high vacuum, compressors
Male & Female (M&F)
Class 150–2500 (all)
Semi-confined soft/spiral
Heat exchangers, vessel covers
YUHAO: Every Facing Type, Every Standard, One Supplier
YUHAO manufactures flanges with all five facing configurations across the full range of standards and pressure classes. Whether your project requires Class 2500 RTJ flanges for a subsea manifold, T&G flanges for a chlorine gas header, or simple FF flanges for a cast iron pump connection — YUHAO delivers them with certified facing dimensions, verified surface finish (Ra/AARH), and full EN 10204 3.1 traceability.
For projects specifying mixed facing types across multiple line classes, YUHAO serves as a single-source partner — eliminating the complexity and risk of multi-vendor facing-type coordination.
