AquaShield Marine: Specialized Stainless Steel Locking Ball Valve for Saltwater Applications
  • name

AquaShield Marine: Specialized Stainless Steel Locking Ball Valve for Saltwater Applications

MOQ: 100kgs
Price: Negotiation
Standard Packaging: Standard sea worth bundles,Standard Plywood cases
Delivery Period: 3-10days
Payment Method: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YUHAO
Certification
ASTM, AISI, GB, DIN, JIS
Model Number
Stainless steel ball valves
Standard:
ASTM, JIS, GB, AISI, DIN, BS,EN
Bonnet Style:
Threaded Or Welded
Applications:
Industrial, Chemical, Oil & Gas, Water Treatment, Etc.
Thread:
NPT, BSPT...
Port Size:
1"-48"
Pressure:
High/Medium/Low Pressure
Working Pressure:
PN，PSI
Color:
Silver,chrome,white,Customer's Request,Grey
Temperature Of Media:
Medium Temperature,Normal Temperature,High Temperature
Highlight:

stainless steel locking ball valve

,

marine ball valve for saltwater

,

AquaShield stainless steel valve

Product Description

 AquaShield Marine: Specialized Stainless Steel Locking Ball Valve for Saltwater Applications


►Products description

Born from decades of maritime engineering experience, AquaShield Marine tackles the unique challenges of saltwater environments. Our proprietary SeaGuard™ coating system provides an extra layer of protection against the most aggressive marine conditions.
Marine-Optimized Innovations​
  • HydroShield™ Technology:​ Nano-coating prevents marine growth and mineral deposition
  • TidalLock™ Mechanism:​ Salt-resistant locking system that won't corrode or seize
  • Cryogenic to Tropical Range:​ Performance-certified from -60°F to 500°F (-51°C to 260°C)
  • Emergency Quick-Release:​ Safety override feature for emergency situations
  • Ultrasonic Testing:​ Each valve undergoes individual pressure and integrity verification
Marine & Offshore Applications​
  • Shipboard ballast and bilge systems
  • Offshore drilling platform fluid control
  • Port and harbor infrastructure
  • Aquaculture and fish farming operations
  • Coastal wastewater treatment plants
Marine Certification Ready​
  • DNV-GL, ABS, and Lloyd's Register compliant
  • 316L stainless steel with extra-low carbon content
  • Maximum working pressure: 1,200 PSI in seawater applications
  • Optional cathodic protection compatibility

►Product size

PN1.6MPa Main connection dimensions and weight

DN 15 20 25 32 40  50 65 80 100 125 150 200
L 130 140 150 165 180   200 220 250 280 320 360 400
H 59 63 75 85 95   107 142 152 178 252 272 342
W 130 130 160 180 230 230 400 400 650 1050 1050 1410
Wt(Kg) 2.5 3 5 6 7 10 15 19 33 58 93 160


PN2.5MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 130 140 150 165 180 200 220 250 320 400 400 550
H 59 63 75 97 107 142 152 178 252 272 342 345
W 130 130 160 230 230 400 400 700 1100 1100 1500 1500
Wt(Kg) 2.5 3 5 6 7.5 10 15 20 33 60 93 175


PN4.0MPa Main connection dimensions and weight

DN 15 20 25 32 40  50 65 80 100 125 150 200
L 130 140 150 180 200 220 250 280 320 400 400 400
H 59 63 75 85 95 107 142 152 178 252 272 342
W 130 130 160 230 230 400 400 700 1100 1100 1500 1500
Wt(Kg) 3 4 5 7 9 12 18 28 46 75 106 190


PN6.4MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 165 190 216 229 241 292 330 356 432 508 559 660
H 59 63 75 97 107 142 152 178 252 272 305 398
W 130 130 160 230 230 400 400 700 1100 1100 1500 1800
WtKg) 6.5 7 8 12 14 18 28 40 65 98 140 250


PN10MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 165 190 216 229 241 292 330 356 432 508 559 660
H 59 63 75 97 107 142 152 178 252 272 305 398
W 130 130 160 230 230 400 400 700 1100 1100 1500 1800
       Wt(Kg) 6.5 7 10 15 18 25 32 46 75 - - -


►Factory Shoot

AquaShield Marine: Specialized Stainless Steel Locking Ball Valve for Saltwater Applications 0

AquaShield Marine: Specialized Stainless Steel Locking Ball Valve for Saltwater Applications 1

AquaShield Marine: Specialized Stainless Steel Locking Ball Valve for Saltwater Applications 2
