Fire-Safe API 607 Certified 2-Piece Lockable Ball Valve
  • name

Fire-Safe API 607 Certified 2-Piece Lockable Ball Valve

MOQ: 100kgs
Price: Negotiation
Standard Packaging: Standard sea worth bundles,Standard Plywood cases
Delivery Period: 3-10days
Payment Method: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YUHAO
Certification
ASTM, AISI, GB, DIN, JIS
Model Number
Stainless steel ball valves
Standard:
ASTM, JIS, GB, AISI, DIN, BS,EN
Bonnet Style:
Threaded Or Welded
Applications:
Industrial, Chemical, Oil & Gas, Water Treatment, Etc.
Thread:
NPT, BSPT...
Port Size:
1"-48"
Pressure:
High/Medium/Low Pressure
Working Pressure:
PN，PSI
Color:
Silver,chrome,white,Customer's Request,Grey
Temperature Of Media:
Medium Temperature,Normal Temperature,High Temperature
Highlight:

API 607 certified ball valve

,

2-piece lockable ball valve

,

fire-safe stainless steel valve

Product Description

Fire-Safe API 607 Certified 2-Piece Lockable Ball Valve


►Products description

This fire-safe stainless steel two-piece lockable ball valve is API 607 certified, offering exceptional performance even under extreme temperatures. The welded two-piece body and lockable handle make it a safe, durable choice for flammable fluid applications.
Key Features​
  • Fire-Safe Certified:​ Meets API 607/ISO 1 Ensure safety with our fire-safe stainless steel two-piece lockable ball valve. API 607 certified, ideal for hazardous environments. Leak-proof, secure, and reliable.0497 standards.
  • Double Block and Bleed:​ Provides additional sealing security.
  • Locking Handle:​ Prevents tampering and accidental operation.
  • Stainless Steel Construction:​ Resists corrosion and thermal deformation.
  • Low Maintenance:​ Long service life with minimal upkeep.
  • Bi-Directional Flow:​ Suitable for multi-directional installation.
Applications​
  • Oil refineries and petrochemical plants
  • LNG and LPG processing
  • Aerospace and defense fluid systems
  • Fire protection systems
  • Hazardous material handling
Technical Specifications​
  • Sizes: 1/2" to 2"
  • Body Material: SS316
  • Pressure Rating: 720 PSI
  • Fire Test: 30 minutes @ 1400°F
  • Seat: Graphite/PTPE
  • End Connection: Butt weld

►Product size

PN1.6MPa Main connection dimensions and weight

DN 15 20 25 32 40  50 65 80 100 125 150 200
L 130 140 150 165 180   200 220 250 280 320 360 400
H 59 63 75 85 95   107 142 152 178 252 272 342
W 130 130 160 180 230 230 400 400 650 1050 1050 1410
Wt(Kg) 2.5 3 5 6 7 10 15 19 33 58 93 160


PN2.5MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 130 140 150 165 180 200 220 250 320 400 400 550
H 59 63 75 97 107 142 152 178 252 272 342 345
W 130 130 160 230 230 400 400 700 1100 1100 1500 1500
Wt(Kg) 2.5 3 5 6 7.5 10 15 20 33 60 93 175


PN4.0MPa Main connection dimensions and weight

DN 15 20 25 32 40  50 65 80 100 125 150 200
L 130 140 150 180 200 220 250 280 320 400 400 400
H 59 63 75 85 95 107 142 152 178 252 272 342
W 130 130 160 230 230 400 400 700 1100 1100 1500 1500
Wt(Kg) 3 4 5 7 9 12 18 28 46 75 106 190


PN6.4MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 165 190 216 229 241 292 330 356 432 508 559 660
H 59 63 75 97 107 142 152 178 252 272 305 398
W 130 130 160 230 230 400 400 700 1100 1100 1500 1800
WtKg) 6.5 7 8 12 14 18 28 40 65 98 140 250


PN10MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 165 190 216 229 241 292 330 356 432 508 559 660
H 59 63 75 97 107 142 152 178 252 272 305 398
W 130 130 160 230 230 400 400 700 1100 1100 1500 1800
       Wt(Kg) 6.5 7 10 15 18 25 32 46 75 - - -


►Factory Shoot

Fire-Safe API 607 Certified 2-Piece Lockable Ball Valve 0

Fire-Safe API 607 Certified 2-Piece Lockable Ball Valve 1

Fire-Safe API 607 Certified 2-Piece Lockable Ball Valve 2
