Stainless Steel Two-Piece Welded Lockable Ball Valve with 800 PSI Pressure Rating
  • name

Stainless Steel Two-Piece Welded Lockable Ball Valve with 800 PSI Pressure Rating

MOQ: 100kgs
Price: Negotiation
Standard Packaging: Standard sea worth bundles,Standard Plywood cases
Delivery Period: 3-10days
Payment Method: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YUHAO
Certification
ASTM, AISI, GB, DIN, JIS
Model Number
Stainless steel ball valves
Standard:
ASTM, JIS, GB, AISI, DIN, BS,EN
Bonnet Style:
Threaded Or Welded
Applications:
Industrial, Chemical, Oil & Gas, Water Treatment, Etc.
Thread:
NPT, BSPT...
Port Size:
1"-48"
Pressure:
High/Medium/Low Pressure
Working Pressure:
PN，PSI
Color:
Silver,chrome,white,Customer's Request,Grey
Temperature Of Media:
Medium Temperature,Normal Temperature,High Temperature
Highlight:

Two-Piece Welded Ball Valve

,

Lockable Handle Stainless Steel Valve

,

800 PSI Lockable Ball Valve

Product Description

Stainless Steel Two-Piece Welded Lockable Ball Valve – Durable & Secure Flow Control


►Products description

The stainless steel two-piece welded lockable ball valve is engineered for demanding industrial fluid control systems. Its robust two-piece welded body ensures structural integrity, while the lockable handle prevents unauthorized operation—making it perfect for critical applications in chemical, water treatment, and oil & gas industries.
Key Features​
  • Two-Piece Welded Design:​ Provides superior strength and leak-proof performance under high-pressure conditions.
  • Lockable Handle:​ Enhances safety by allowing the valve to be locked in open or closed positions.
  • Full Port Design:​ Minimizes pressure drop and allows unrestricted fluid passage.
  • Stainless Steel Construction:​ Offers excellent corrosion resistance, suitable for aggressive media.
  • Fire-Safe Design:​ Meets industry standards for fire-safe applications.
  • Temperature Range:​ -20°F to 400°F (-29°C to 204°C).
  • Pressure Rating:​ Up to 800 PSI.
Applications​
  • Chemical and petrochemical processing
  • Water and wastewater treatment
  • Oil and gas pipelines
  • HVAC and industrial heating systems
  • Marine and offshore installations
Technical Specifications​
  • Size Range: 1/2" to 2"
  • Material: SS304/SS316
  • End Connections: Butt weld, socket weld
  • Seat Material: PTFE/RPTFE
  • Standards: API 608, ISO 17292


►Product size

PN1.6MPa Main connection dimensions and weight

DN 15 20 25 32 40  50 65 80 100 125 150 200
L 130 140 150 165 180   200 220 250 280 320 360 400
H 59 63 75 85 95   107 142 152 178 252 272 342
W 130 130 160 180 230 230 400 400 650 1050 1050 1410
Wt(Kg) 2.5 3 5 6 7 10 15 19 33 58 93 160


PN2.5MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 130 140 150 165 180 200 220 250 320 400 400 550
H 59 63 75 97 107 142 152 178 252 272 342 345
W 130 130 160 230 230 400 400 700 1100 1100 1500 1500
Wt(Kg) 2.5 3 5 6 7.5 10 15 20 33 60 93 175


PN4.0MPa Main connection dimensions and weight

DN 15 20 25 32 40  50 65 80 100 125 150 200
L 130 140 150 180 200 220 250 280 320 400 400 400
H 59 63 75 85 95 107 142 152 178 252 272 342
W 130 130 160 230 230 400 400 700 1100 1100 1500 1500
Wt(Kg) 3 4 5 7 9 12 18 28 46 75 106 190


PN6.4MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 165 190 216 229 241 292 330 356 432 508 559 660
H 59 63 75 97 107 142 152 178 252 272 305 398
W 130 130 160 230 230 400 400 700 1100 1100 1500 1800
WtKg) 6.5 7 8 12 14 18 28 40 65 98 140 250


PN10MPa Main connection dimensions and weight

DN 15 20 25 32 40 50 65 80 100 125 150 200
L 165 190 216 229 241 292 330 356 432 508 559 660
H 59 63 75 97 107 142 152 178 252 272 305 398
W 130 130 160 230 230 400 400 700 1100 1100 1500 1800
       Wt(Kg) 6.5 7 10 15 18 25 32 46 75 - - -


►Factory Shoot

Stainless Steel Two-Piece Welded Lockable Ball Valve with 800 PSI Pressure Rating 0

Stainless Steel Two-Piece Welded Lockable Ball Valve with 800 PSI Pressure Rating 1

Stainless Steel Two-Piece Welded Lockable Ball Valve with 800 PSI Pressure Rating 2
