RC Thread F304 F316 F316L Stainless Steel Screwed Fittings 45 Degree Npt Elbow
  • name

RC Thread F304 F316 F316L Stainless Steel Screwed Fittings 45 Degree Npt Elbow

MOQ: 100kgs
Price: Negotiation
Standard Packaging: Standard sea worth bundles,Standard Plywood cases
Delivery Period: 5-15days
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 2000tons/per month
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YUHAO
Certification
ASTM, AISI, GB, DIN, JIS
Model Number
Screwed pipe fittings
Shape:
Elbow
Connection Type:
Threaded Or Socket Welded
Application:
Connection, Decoration, Oil And Gas, Automative, New Energy, Chemical
End Type:
Female
Thread Type:
NPT/BSPT/RC/R
Material:
F304 F316 F316L F304L
Standard:
DIN,ANSI,ASTM,JIS,GB
Packing:
Wooden Case,Bags，pallets
Brand:
Yuhao
Highlight:

RC thread stainless steel screwed fittings

,

F316L stainless steel screwed fittings

,

F304L 45 degree npt elbow

Product Description

DIN,ANSI,ASTM,JIS,GB F304 F316 F316L F304L Screwed Pipe Fittings 45Degree Threaded Elbow



►Products description

A stainless steel 45-degree internal thread elbow is a precision-engineered pipe fitting designed for seamless directional changes in piping systems. Made from high-quality stainless steel grades such as 304, 304L, 316, or 316L, it offers excellent corrosion resistance, durability, and mechanical strength. The internal threads ensure a secure and leak-proof connection, making it ideal for applications in industries like oil & gas, chemical processing, and water treatment. Available in various sizes (DN15-DN1200) and pressure ratings (SCH5S-SCH160), this elbow is customizable to meet specific requirements. Its 45-degree angle facilitates smooth fluid flow, reducing turbulence and pressure loss. With a polished or brushed finish, it is suitable for both industrial and sanitary applications.



►Products Size

DN NPS OD Nominal Wall Thickness
Schss Sch10S Sch405 Sch8os Sch10 Sch20 Sch30 STD Sch40 Sch60 XS
6 1/8 10.3 - 1.24 1.73 2.41 - - - 1.73 1.73 - 2.41
8 1/4 13.7   1.65 2.24 3.02 - - - 2.24 2.24 - 3.02
10 3/8 17.1 - 1.65 2.31 3.2 - - - 2.31 2.31 - 3.2
15 1/2 21.3 1.65 2.11 2.77 3.73 - - - 2.77 2.77 - 3.73
20 3/4 26.7 1.65 2.11 2.87 3.91 - - - 2.87 2.87 - 3.91
25 1 33.4 1.65 2.77 3.38 4.55 - - - 3.38 3.38 - 4.55
32 1 1/4 42.2 1.65 2.77 3.56 4.85 - - - 3.56 3.56 - 4.85
40 1 1/2 48.3 1.65 2.77 3.68 5.08 - - - 3.68 3.68 - 5.08
50 2 60.3 1.65 2.77 3.91 5.54 - - - 3.91 3.91 - 5.54
65 2 1/2 73 2.11 3.05 5.16 7.01 - - - 5.16 5.16 - 7.01
80 3 88.9 2.11 3.05 5.49 7.62 - - - 5.49 5.49 - 7.62
90 3 1/2 101.6 2.11 3.05 5.74 8.08 - - - 5.74 5.74 - 8.08
100 4 114.3 2.11 3.05 6.02 8.56 - - - 6.02 6.02 - 8.56
125 5 141.3 2.77 3.4 6.55 9.53 - - - 6.55 6.55 - 9.53
150 6 168.3 2.77 3.4 7.11 10.97 - - - 7.11 7.11 - 10.97
200 8 219.1 2.77 3.76 8.18 12.7 - 6.35 7.04 8.18 8.18 10.31 12.7
250 10 273 3.4 4.19 9.27 12.7 - 6.35 7.8 9.27 9.27 12.7 12.7
300 12 323.8 3.96 4.57 9.53 12.7 - 6.35 8.38 9.53 10.31 14.27 12.7
350 14 355.6 3.96 4.78 - - 6.35 7.92 9.53 9.53 11.13 15.09 12.7
400 16 406.4 4.19 4.78 -   6.35 7.92 9.53 9.53 12.7 16.66 12.7
450 18 457 4.19 4.78 - - 6.35 7.92 11.13 9.53 14.27 19.05 12.7
500 20 508 4.78 5.54 - - 6.35 9.53 12.7 9.53 15.09 20.62 12.7





►Shotp Shoot

RC Thread F304 F316 F316L Stainless Steel Screwed Fittings 45 Degree Npt Elbow 0RC Thread F304 F316 F316L Stainless Steel Screwed Fittings 45 Degree Npt Elbow 1RC Thread F304 F316 F316L Stainless Steel Screwed Fittings 45 Degree Npt Elbow 2



►FAQ

Q1: Do you provide samples ? Is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.



Q2: Delivery time?

A: 1- 7 days for small order.10- 20 days for big order.



Q3: What is your minimum order quantity?

A: The MOQ for each product is different, so it would be recommended to refer to the detail page of the product you are interested in. If you need further clarification, send me the product link, and I will reply as soon as possible.



Q4: How is the quality about the products?

A: Quality is priority. We pay much attention to the quality check. Every product will be fully assembled and carefully tested before it's packed for shipment.



Q5: How long is your production lead time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
